3T Maeda MC305C-2 Spider Crane Hire Melbourne
2.98T Mini Crawler Crane for Glazing, Plant, Steel & Restricted-Access Construction
Crane2U provides 3T spider crane hire in Melbourne using the Maeda MC305C-2. Maeda rates this mini crawler at 2.98 t × 2.5 m, with a maximum working radius of 12.16 m at 0.26 t and a maximum lifting height of 12.52 m. It sits between the narrow MC285C-3 and the larger MC405C-3, giving more reach while retaining crawler access and compact spider-crane setup characteristics.
This model suits glass installation, machinery placement, plant rooms, structural components, HVAC equipment and other work where a larger mobile crane cannot be positioned close enough to the load. The rated 2.98 t figure applies at the stated short radius only; the actual lift must be checked against the MC305C-2 load chart and site configuration.
Maeda MC305C-2 Specifications
Specification | Model-specific technical data |
|---|---|
Crane capacity | 2.98 t × 2.5 m |
Maximum working radius | 12.16 m × 0.26 t |
Maximum lifting height | 12.52 m |
Maximum reach below ground | -16.09 m (4 falls) |
Boom length | 3.695 m to 12.485 m |
Stowed dimensions | 4,285 mm (L) × 1,280 mm (W) × 1,695 mm (H) |
Machine weight | Approx. 3,900 kg; electric configuration varies |
Maximum outrigger spread | Lateral 4,888 mm; front 4,504 mm; rear 4,396 mm |
Travel speed | 0-2.8 km/h |
Power | Diesel; electric motor option depending on configuration |
*Maximum capacities are manufacturer headline ratings at the stated short radius. They are not the capacity available at every radius. Confirm the exact Crane2U machine configuration and current load chart before quoting or publishing any lift-specific capacity.
Compare the 2.8T, 3T & 4T Crawler Cranes
The correct mini crawler is selected from the actual load, working radius, hook height, access route, setup area and floor or ground conditions. Nominal tonne rating alone does not determine suitability. Compare the range below, then confirm the lift against the current crane specifications and load chart.
2.8T Crawler Spider Crane
3T Crawler Spider Crane
4T Crawler Spider Crane
Why Choose the MC305C-2?
- Longer reach than the MC285C-3 while retaining a compact crawler-based crane format for constrained sites.
- 2.98 t headline capacity at 2.5 m and 12.16 m maximum working radius give this class more flexibility for construction and placement work.
- Useful for glazing, structural steel, machinery and building-services lifts where the machine must travel into the site before setting outriggers.
- 12.52 m maximum lifting height covers many internal, courtyard and low- to mid-rise placement tasks without stepping up to the larger MC405C-3.
- Optional electric power exists on the model family; advertise indoor/electric capability only if the Crane2U unit is fitted and the building conditions allow it.
Common 3T Crawler Applications
Glass & Facade Installation
Our 3T spider crawler crane is suited to glass lifting, shopfront glazing, window installation and facade panel placement across Melbourne. Its compact design supports controlled lifting in narrow-access construction sites, courtyards and commercial developments. Explore our glass lifting services in Melbourne
Structural Steel & Residential Construction
Hire a 3 tonne mini crawler crane for lifting steel beams, lintels, roof trusses, frames and construction materials on residential and commercial projects. Ideal for restricted-access building sites requiring precise steel placement. Learn more about our crawler spider crane hire options.
HVAC & Mechanical Equipment Lifting
Our 3T crawler crane supports air-conditioning installation, mechanical plant lifting and positioning of pumps, generators and other equipment. Suitable for rooftop, courtyard and plant-room projects where conventional mobile crane access is limited. Crane selection depends on the load and site conditions.
Indoor Lifting & Restricted-Access Construction
Our compact 3T spider crane can assist with equipment installation, warehouse fit-outs and machinery placement in confined construction areas. Suitable for projects in Melbourne, Melton, Bacchus Marsh, Geelong and Ballarat, subject to access and floor-load assessments. Read about the benefits of spider crane hire for tight spaces.
How the Crawler Crane Hire Process Works
Step | What to provide / what happens |
1. Send the access and lift details | Site address, load weight and dimensions, pick point, landing point, approximate working radius, required hook height, narrowest access width/height, ground or floor conditions and site photos. |
2. Match the machine | Crane2U checks whether the 2.8T crawler crane is appropriate against the available fleet, current specifications and load-chart requirements. |
3. Confirm site support | Operator, rigging, dogman, electrical spotter, lift planning, ground/floor protection and transport requirements are confirmed where applicable. |
4. Deliver, position and complete the lift | The agreed crawler crane is transported to site, tracked into the approved setup area and used to complete the lifting scope in line with the confirmed plan. |
Need a Reliable Crane for Your Next Project?
Tell us what you are lifting, where it needs to go and what access is available. Crane2U can recommend a suitable crane and supporting services for the job.
Crane Hire & Restricted-Access Support
Restricted-access lifts often need more than a crane. Crane2U can coordinate supporting services around the actual site conditions and lifting plan.
Wet & Dry Crane Hire
Flexible crane hire options matched to the project, crew requirements and operating arrangements.
Engineered Lift Planning
Planning support for complex or higher-risk lifts, including lift methodology and site considerations.
Dogman & Riggers
Qualified lifting support for rigging, load control, signalling and safe crane operations.
Electrical Spotters
Qualified spotter support for crane and plant operations near electrical hazards and powerlines.
Transport Services
Transport support for machinery, equipment and project materials across Melbourne and Regional Victoria.
Tracked Carrier Hire
Tracked material-handling support where loads need to move through soft, rough or restricted-access areas.
3T Spider Crane Hire Across Melbourne & Victoria
Crane2U can assess MC305C-2 hire across Melbourne and Regional Victoria, including Melton, Bacchus Marsh, Maddingley, Werribee, Caroline Springs, Maidstone, Sunshine, Footscray, Altona, Truganina, Point Cook, Gisborne, Geelong, Ballarat and surrounding areas. Send the site address and access measurements so mobilisation and machine suitability can be reviewed together.
View all Crane2U crane hire service areas or send the project address to confirm mobilisation and availability.
Common 3T Crawler Applications
Steel & Structural Components
Suitable beams, frames, posts, bracing and fabricated sections for construction and fit-out projects.
HVAC & Rooftop Services
Mechanical equipment and rooftop plant where the crawler can operate closer to the lift point.
Glass & Facade Installation
Windows, shopfronts, balustrades and glazing components that need controlled placement.
Electrical Equipment
Transformers, switchboards and related equipment where access and supporting crew need careful planning.
Plant & Equipment Placement
Pumps, generators, machinery and other suitable plant installed through restricted access routes.
Precast & Construction Components
Suitable precast and construction elements positioned within the approved crane capacity and setup conditions.
3T crawler crane Hire Across Melbourne & Regional Victoria
Crane2U provides 3t crawler crane hire from its Maddingley base for projects across Melbourne and Western Victoria, including Maidstone, Werribee, Caroline Springs, Melton, Bacchus Marsh, Geelong, Ballarat, Gisborne and surrounding growth corridors. Regional work can also be assessed for Ballan, Darley, Rockbank, Eynesbury, Brookfield, Cobblebank, Weir Views, Bonnie Brook, Melton South, Strathtulloh and Thornhill Park. View all Crane2U crane hire service areas or send the project address to confirm mobilisation and availability.
How the Crawler Crane Hire Process Works
1. Send the access and lift details | Site address, load weight and dimensions, pick point, landing point, approximate working radius, required hook height, narrowest access width/height, ground or floor conditions and site photos. |
2. Match the machine | Crane2U checks whether the 4T crawler crane is appropriate against the available fleet, current specifications and load-chart requirements. |
3. Confirm site support | Operator, rigging, dogman, electrical spotter, lift planning, ground/floor protection and transport requirements are confirmed where applicable. |
4. Deliver, position and complete the lift | The agreed crawler crane is transported to site, tracked into the approved setup area and used to complete the lifting scope in line with the confirmed plan. |
Need a Reliable Crane for Your Next Project?
Tell us what you are lifting, where it needs to go and what access is available. Crane2U can recommend a suitable crane and supporting services for the job.
How much can the Maeda MC305C-2 lift?
The MC305C-2 is rated at 2.98 t at 2.5 m radius. At the maximum working radius of 12.16 m, the manufacturer headline figure is 0.26 t. Always use the applicable load chart for the actual boom and outrigger configuration.
How high can the MC305C-2 lift?
The model-specific technical data lists a maximum lifting height of 12.52 m on the main boom.
Is the MC305C-2 suitable for glass installation?
Yes, it can suit glazing and facade placement when the crane chart, access route, vacuum lifter and panel requirements all match the job.
What is the difference between the MC285C-3 and MC305C-2?
The MC285C-3 is much narrower at 750 mm and focuses on extreme access. The MC305C-2 is wider but offers more rated capacity at its headline radius and a longer 12.16 m maximum working radius.
Where is 3T spider crane hire available?
Crane2U can assess 3T spider crane hire across Greater Melbourne, Melbourne’s west, Geelong, Ballarat and other Regional Victoria locations.
Where is 3T crawler crane hire available?
Crane2U services Melbourne and Western Victoria including Maidstone, Werribee, Caroline Springs, Melton, Bacchus Marsh, Geelong, Ballarat, Gisborne and surrounding areas.
